100L Falling Type Plastic Mixer For Artificial Leather

1. Technical parameter

• Total cubage: 100L

• Rotary speed of front roll: 40r/min;

• Rotary speed of back roll: 34r/min;

• Motor power: AC 220kw/380W/50Hz;

• Oil heating or steam heating type;

2. Main character

• Precision roller sphere bearing;

• Compulsory lubrication;

This machine can open the discharge door by person when the electric is off;

3. Equipment list

1 main body 1 group

2 press hammer and cylinder 1 group

3 material feeding device 1 group

4 discharge device 1 group

5 transmission device 1 group

6 electric control device 1 group

7 oil pressure and lubricate device 1 group

8 tubing 1 group

4. Applications:

• PVC Artificial Leather
• PVC film
• PVC plastic floor
• PVC plastic sheet
• Plastic mixer
• Rubber mixer

5. Main Technical Parameter:

6. Competitive Advantage:

• PLC control system

• Lower noise,safer mixer

• Excellent dispersing effect

• Best mixing chamber to get 100% mixing effect.

• Fast Mixing,good effectivity

• Easier Maintenance.

• Long life.

• No leakage.

7. Service:

• Oversea installation guide.

• Oversea test running

• Oversea worker training

• Technical support

• Spare parts supply supply of spare parts

• Technical operation support

• Formula and processing support

8. Option

Two rotor mixer, the relative rotation, the material from the feed mouth clamp into the roll gap by rotor extruding and shearing, after through the roll gap above the top tied pien is divided into two parts, respectively along the chamber wall and the gap between the rotor before and after the return to roll gap above.In a week around the rotor flow, material is influenced by the shear and friction action, make rubber temperature rise sharply, lower viscosity, increased the wettability on the surface of the rubber in the compound, make good contact with rubber and compound surface.

9. commercial terms

1. Payment: 30% by T/T as advance payment, balance(70%) by T/T before shipment

2. Lead Time: 60 days after receiving the advance payment

3. Transportation: container, simple package ( PE film, salver)

4.Warranty period: From the day of the use of the machine in the buyer’s factory:

(1) The mechanical Parts: 12 months

(2) The electrical Parts: 6 months

5. Installations and Commissioning

(1) Up to date Last commissioning will have been made before shipment

(2) Overseas Commissioning and charges

one or two technicians will be sent to the buyer to guide the installation and commissioning of the equipment if the customer requests.

Customers pay the charge of our technicians.

(1) Round-trip Airplane Ticket

(2) Charges of transportation, accommodation and communication

(3) The allowance for the technicians is USD 80 per day for one person.

(4) An interpreter is needed.

6. Spare parts:

Spare parts for one year are needed for the customers, and we suggest that customers should buy the spare parts. (Fittings list will be provided.)

7. English manual, Figuration drawing, and footing drawings are provided.
