    Around the borehole roll PVC Calender Machine / calendering equipment

    Ask Lasest Price
    Brand Name : FLAME
    Model Number : Ø610mm×2030mm Calender
    Certification : ISO9001:2000,CE
    Price : USD 900,000~1,100,000,000/line
    Payment Terms : T/T
    Supply Ability : two lines/150 days
    Delivery Time : 150 working days
    • Product Details
    • Company Profile

    Around the borehole roll PVC Calender Machine / calendering equipment

    1 . Introduction of Product
    Around the borehole roll Low Noisy 4 Roll Calender Machine Soft PVC Calender Equipment
    Around the borehole roll PVC Calender Machine / calendering equipment
    1. 610mmX2030mm calender machine is composed of Mixer unit Planetary extruder Open mill Strainer extruder Four-roll calendar, heat lead deice, embossing machine and auxiliary cooling machine etc.
    2. The calender machine is suitable for the production of PVC soft film, semi-hard color film rolls in the thickness range of 0.05-0.80mm with the thickness tolerance ≤0.01mm.
    3. Calendar roll adopts independent driving in conjunction with special rigid gear reducer; options include preload, anti-curving device and hydraulic axle crossover device.

    2. Quick Detail:

    iterms

    the name of the equipment

    1

    SRL-Z500/1000A mixer unit

    2

    PRE-255 Planetary extruder

    3

    660mmX2300mm Rolling turbine

    4

    610mmX2030mm Rolling turbine

    5

    SJL-250 filter extrder

    6

    610mmX1830mm calender

    7

    Assembly Equipment

    8

    DC motor and control equipment

    9

    Temperature control system of calendar

    10

    4 Conveyors and 3 waste scrap of leading machine


    3. Description:

    Iterm

    Name

    standard

    1-1

    type

    Reverse “L” Four roller calender

    1-2

    Size of Roller

    24″(610M/M)X80″L(2030M/M)

    1-3

    Type of Roller

    4 Drilling wheels
    Texture : Cold shock hardfacing alloy cast iron

    1-4

    The width of production

    1500mm-1700mm

    1-5

    Main motor

    75KW 2 sets, 90KW 2sets

    1-6

    Main reduction gears

    Four independent type combination

    1-7

    Rotate speed of roller

    6-60M/MIN

    1-8

    gap adjustment

    digital display, high-low two stage speed adjustment

    1-9

    Parts of roller

    Upper roller: overhang
    Middle roller: gap eliminated
    Bottom of roller: preload device

    1-10

    Main bearing lubrication

    Forced lubrication oil cycling

    1-11


    Security protection

    Emergency safety brake, Loss of oil pressure protection by closing down, fault indicating lamp and other type of open the device of hydraulic type power failure


    Around the borehole roll PVC Calender Machine / calendering equipmentAround the borehole roll PVC Calender Machine / calendering equipmentAround the borehole roll PVC Calender Machine / calendering equipmentAround the borehole roll PVC Calender Machine / calendering equipmentAround the borehole roll PVC Calender Machine / calendering equipment

    4. Applications:
    It is uesd to produce farm film, package color film, transparent film and etc.

    5. Specifications:

    Type

    SY-4ΓФ560x1830

    SY-4ΓФ610x2030

    SY-4ΓФ660x2300

    SY-4ΓФ760x2800

    SY-4ΓФ860x4000

    Roller Specifications (mm)

    Ф560x1830

    Ф610x2030

    Ф660x2300

    Ф760x2800

    Ф860x4000

    Thickness of rolled products(mm)

    0.08-0.8

    0.08-0.8

    0.08-0.8

    0.08-0.8

    0.09-0.35

    Width rolled products (mm)

    1400-1550

    1600-1750

    1900-2050

    2300-2500

    3000-3200

    Main motor power(KW)

    45KWx2; 55KWx2

    55KWx2; 75KWx2

    75KWx2; 90KWx2

    90KWx2; 110KWx2

    110KWx2;150KWx2



    6. Competitive Advantage:
    a. The rollers are drilled roll with hot-grinded, single motor single transmission with a stable and adjustment speed work. The machine use roller bearing which can bear high temperature. Sealing type is labyrinth.
    b. The film can infinite extend, with a high work speed, high produce capacity, good quality and uniform thickness.
    c. The main machine has roll crossing, preloading and anti-bending device, the nip adjustment speed can be adjusted, the electric parts has PLC control.

    7. Service:

    1. Oversea installation guide.
    2. Oversea test running
    3. Ovsersea worker training
    4. Technical support
    5. Spare parts supply
    6. Technical operation support
    7. Formula and processing support

    8. Option
    SRL-Z500/1000A Mixer unit →PRE-255 Planetary extruder -→SK-Φ660×2300mm Open Mixing Mill—→SK-Φ610×2030mm Open Mixing Mill-→SJL-250 Filter Extruder —→SY-4ГΦ610×2030mm Four Roller Calender—→SY-4ГΦ610×2030mm Assembly Equipment of Four Roller Calender


    9. Commercial terms
    1. Payment: 30% by T/T as advance payment, balance(70%) by T/T before shipment
    2. Lead Time: 120 days after receiving the advance payment
    3. Transportation: container, simple package ( PE film, salver)
    4.Warranty period: From the day of the use of the machine in the buyer’s factory:
    (1) The mechanical Parts: 12 months
    (2) The electrical Parts: 6 months
    5. Installations and Commissioning
    (1) Up to date commissioning has been made before shipment
    (2) Overseas Commissioning and charges one or two technicians will be sent to the buyer to guide the
    installation and commissioning of the equipment if the customer requests.
    Customers pay the charge of our technicians.
    (1) Round-trip Airplane Ticket
    (2) Charges of transportation, accommodation and communication
    (3) The allowance for the technicians is USD 80 per day for one person.
    (4) An interpreter is needed.
    6. Spare parts:
    Spare parts for one year are needed for the customers, and we suggest that customers should buy the spare parts. (Fittings list will be provided.)
    7. English manual, Figuration drawing, and footing drawings are provided.
